GEM CAMEL HW134
This motor gear box is desigend and manufactured in compliance with European lift directive 95/16/EC-EN81.1,for the 3,4,6 persons lift and speed up to 1 m/s.
Description
Worm wheel & Worm shaft, running on high precision utmost quality ball bearings for the axial constrain.Noise level below 60 Db and one of the outstanding characteristic is the possibility to disassemble completely the machine into sub-components and reinstall them easily in the site.
This motor gear box is produced by Gem company in Italy and distributed in all around Iran by Behran lift Co.as the exclusive sales agent for Gem company's products in this country.
.
Technical data
| Interasse - Distance between slow and fast shafts | 134 mm |
|---|---|
| Carico statico max. - Max static load | 2.300 Kg (senza supporto esterno) (without external support) 2.700 Kg (con supporto esterno) (with external support) |
| Coppia massima in uscita - Max output torque | 1.012 Nm |
| Rapporti di riduzione - Reduction ratio | 1/42 - 1/53 - 1/65 |
| Potenza motore max. - Max motor power | 5.5 KWasy (50 Hz) - 5.8 KWasy (60 Hz) |
| Tipo motore - Motor type | AC1, AC2, ACVV, VVVF |
| Efficienza media riduttore - Average gear efficiency | 0.7 |
| Diametri pulegge di trazione - Diameter of traction sheave | mm 480, mm 550, mm 600 |
| Elettromagnete freno - Electromagnetic brake | 24V, 48V, 60V, 110V, 200V |
| Olio sintetico - Synthetic oil | 3 lt (lubrificato a vita) - (lubricated for life) |
| Peso medio argano - Average weight of the machine | 220 Kg |
Useful load vs. speed table - examples (50 hz - 1500 rpm)
| Portata Load (Kg) | Velocità Speed (m/s) | Rapporto di riduzione Reduction ratio | Diametro puleggia Sheave diameter (mm) | Potenza motore AC2 Motor power AC2 (KWasy ) | Potenza motore VVVF Motor power VVVF (KWasy ) |
|---|---|---|---|---|---|
| 300 | 0.66 | 65/1 | 550 | 2.2 <3.5 Hp> | 2.2 <3.5 Hp> |
| 320 | 0.66 | 65/1 | 550 | 3.0 <4.5 Hp> | 3.0 <4.2 Hp> |
| 320 | 0.72 | 65/1 | 600 | 3.4 <5.0 Hp> | 3.4 <4.8 Hp> |
| 320 | 0.82 | 53/1 | 550 | 3.7 <5.5 Hp> | 3.7 <5.2 Hp> |
| 320 | 0.89 | 53/1 | 600 | 3.7 <5.5 Hp> | 3.7 <5.2 Hp> |
| 480 | 0.66 | 65/1 | 550 | 4.0 <6.0 Hp> | 4.0 <5.7 Hp> |
| 480 | 0.71 | 53/1 | 480 | 4.5 <6.7 Hp> | 4.5 <6.4 Hp> |
| 480 | 0.82 | 53/1 | 550 | 5.0 <7.4 Hp> | 5.0 <7.0 Hp> |
| 480 | 1.03 | 42/1 | 550 | 5.5 <8.1 Hp> | 5.5 <7.8 Hp> |
